BLOCK SWITCHBOARD SYSTEM
Local Price :
BDT 0.00/ Acre. 0.00 / Acre | Get Latest Price
FOB Price :
BDT 0.00-0.00 / Acre | Get Latest Price
Min.Order Quantity :
1 Unit
Supply Ability :
1 Unit per Day
Port :
Payment Terms :
Code :
28297
Model NoMH2 3×1200
Brand NameETA-COM B NV
OriginNetherlands
Size
Packaging & Delivery
Packaging Details
Delivery Details
BLOCK SWITCHBOARD SYSTEM
New Surplus Block Switchboard System, New unused complete switchboard system. Available due to a cancelled project. More Information
Offered at a discount price for new equipment
Also available complete Telcom communications system
MANUFACTURER: ETA-COM B NV
TYPE: MH2 3×1200
EQUIPMENT 5-SW-5-2/BD
PROTECTION CLASS: IP68-IK10
RATED SERVICE VOLTAGE: 690V
RATED INS.VOLTAGE MAIN BUSBARS: 1000 V
RATED FREQUENCY: 50 Hz
RATED IMPULSE WITHSTAND VOLTAGE FOR MAIN BUSBARS: 12 kV
RATED SHORT TIME WITHSTAND CURRENT: 114 kA
MAIN BUSBAR RATED CURRENT: 2500 A @ 40° C/MAX 45 °C
Technical data proposed busducts: 3 phase busduct (segregated phase)
|
690 V / 2500 A |
Requirements |
|
|
betobar-r type Standard |
MH2 3 x 1200 IEC 60439 |
|
|
Conductors :
Section phase mm² Section neutral mm² Section earth mm² |
Copper E-cu 57
1200 mm² N/A N/A |
|
|
Insulation voltage Impulse withstand voltage |
1000 V / 50 Hz 12kV |
690 V |
|
Encapsulation |
Epoxy resin compound (IEC60331 & 2) |
|
|
Metallic Enclosure Painting |
None N/A |
|
|
Nominal current rating at 35°C / max 40°C at 40°C / max 45°C at 42°C / max 47°C |
2630 A 2500 A 2445 A |
2500 A |
|
Short-circuit withstand thermal rms 1 sec dynamic |
114 kA 150 kA |
50 kA |
|
Degree of protection |
IP68-IK10 |
|
|
Weight copper kg/m |
36.80 |
|
|
Weight total kg/m |
85.00 |
|
|
Dim. width x height (mm) |
350 x 140 |
